Description

Next-Generation ABC N-Type Solar Panel with Up to 24.4% Efficiency

The AIKO Stellar ABC N-Type Solar Panel is a premium high-efficiency photovoltaic module designed for maximum power generation and long-term reliability. With a power output range of 625W to 660W and module efficiency reaching up to 24.4%, this solar panel represents one of the most advanced solar technologies available today.

The panel is engineered with superior temperature performance, ultra-low degradation, and advanced shading optimization, ensuring reliable energy production even under challenging environmental conditions. With a 30-year linear performance warranty and only ≤0.35% annual degradation, the AIKO Stellar module guarantees consistent power output over decades.

Available through US Solar Enterprises, delivering high-performance solar equipment for residential, commercial, and industrial solar systems.
Key Features

ABC N-Type Cell Technology

Advanced All Back Contact (ABC) N-Type cells maximize light absorption and improve energy conversion efficiency.

Ultra-High Efficiency

Achieves module efficiency of up to 24.4%, enabling higher power output from smaller installation areas.

Premium Grid-Free Design

No visible grid lines on the front side, providing a sleek, modern appearance and enhanced light absorption.

Superior Power Output

Available power range of 625W to 660W, delivering more energy per module.

Low Degradation Rate

First-year degradation ≤1%, followed by ≤0.35% annual degradation from year 2 to 30.

Enhanced System Performance

Optimized BOS (Balance of System) reduces mounting, cabling, and installation costs.

Shading Optimization

Advanced design improves performance in partial shading conditions.
Technical Specifications
  • Model Series: AIKO-G-MCH72Mw
  • Power Range: 625W – 660W
  • Maximum Efficiency: 24.4%
  • Solar Cell Technology: ABC N-Type
  • Module Type: Mono-Glass
  • Power Tolerance: ±3%

Electrical Characteristics (Example – 660W Module)

  • Maximum Power (Pmax): 660W
  • Maximum Power Voltage (Vmp): 45.30V
  • Maximum Power Current (Imp): 14.57A
  • Open Circuit Voltage (Voc): 54.60V
  • Short Circuit Current (Isc): 15.24A
  • Module Efficiency: 24.4%

Mechanical Specifications

  • Cell Type: N-Type ABC
  • Number of Cells: 144 (6 × 24)
  • Module Dimensions: 2382 × 1134 × 30 mm
  • Weight: 31.5 kg
  • Front Glass: 3.2 mm Tempered Mono Glass
  • Frame: Anodized Aluminum Alloy
  • Junction Box: IP68 Rated with Three Bypass Diodes
  • Connector: MC4 EVO2 Compatible
  • Cable Size: 4 mm²
  • Cable Length: 350 mm

Operating Conditions

  • Operating Temperature: −40°C to +85°C
  • Maximum System Voltage: 1500V DC
  • Maximum Series Fuse Rating: 25A
  • Protection Class: Class II
  • Maximum Static Loading
  • Front: 5400 Pa
  • Back: 2400 Pa

Temperature Coefficients

  • Temperature Coefficient of Pmax: −0.26 % / °C
  • Temperature Coefficient of Voc: −0.22 % / °C
  • Temperature Coefficient of Isc: +0.05 % / °C

Warranty

  • Product Warranty: 15 Years
  • Performance Warranty: 30 Years Linear Power Warranty
  • First-Year Degradation: ≤1%
  • Annual Degradation (Year 2–30): ≤0.35%

Solar Generators

Shop now

Solar Panels

Shop now

Frequently asked questions
What is the power range of the AIKO Stellar solar panel?

The panel provides power output between 625W and 660W.
What technology does this module use?

It uses ABC (All Back Contact) N-Type solar cell technology.
What is the efficiency of this solar panel?

The panel achieves up to 24.4% efficiency, one of the highest in the market.
What warranty does AIKO provide?

The module includes 15-year product warranty and 30-year linear power warranty.
What advantage does ABC technology provide?

ABC technology eliminates front grid lines, increasing efficiency and improving the panel’s appearance.
