Lynx A G4 Series 16kWh | Low Voltage Battery | IP65

Rs.705,000.00

Lynx A G4 Series 16kWh | Low Voltage Battery | IP65

Name: Lynx A G4 Series 16kWh | Low Voltage Battery | IP65
Brand: US Solar Enterprises
Price: 705000.00 PKR
Availability: InStock

Rs.705,000.00

Explore Full Specifications

The Dyness PowerBrick Max / SC 16kW (16.07kWh) is a high-capacity, low-voltage (51.2V) LiFePO4 battery designed for residential and commercial solar setups.

314Ah Cells, 10000 Cycles: Built for long-term reliability

Nominal Capacity: 16.07 kWh (15.27 kWh usable)
Voltage: 51.2V (Working range: 44.8V – 57.6V)
Current & Power: 314Ah capacity with 200A max charge/discharge and 10.24 kW max power
Cycle Life: 8,000+ cycles
Scalability: Parallel expansion up to 50 units (no HUB required, ranging up to ~803 kWh)
Protection Rating: Available in IP20 (indoor) or IP65 (outdoor/weatherproof variants)
Safety: Built-in intelligent fire extinguishing system (reacts within 5 seconds) and smart Wi-Fi/app monitoring
Compatibility: Works with major hybrid/off-grid inverters like Deye, Growatt, Victron, Solis, and GoodW

Battery Chemistry: LiFePO4 (LFP)
Nominal Energy: 16.076 kWh
Usable Energy: 15.272 kWh (at 95% Depth of Discharge)
Nominal Voltage: 51.2 V
Operating Voltage Range: 44.8 V – 57.6 V
Nominal Capacity: 314 Ah

Solar Generators

Shop now

Solar Panels

Shop now

Frequently asked questions

It is compatible with mainstream low-voltage hybrid and off-grid inverters, including Deye, Victron, SMA, Goodwe, Solis, and Growatt.

Standard models like the PowerBrick SC/Max carry an IP20 rating for indoor use, whereas the PowerBrick Plus/Pro variants carry an IP65 rating suitable for outdoor or semi-exposed installation.

Dyness provides a 10-year warranty for the PowerBrick series
