Description

51.2V 102Ah Wall Mounted LiFePO4 Battery (5.12kWh)

The CoreTECH ES-BOX42 (Luxwatt Series) is a compact and efficient wall-mounted LiFePO4 battery system designed for modern residential energy storage. With a capacity of 5.12kWh, this battery provides reliable backup power and seamless integration with solar systems and hybrid inverters.
Key Features

Reliable Energy Storage

  • 5.12kWh usable energy
  • Ideal for residential solar and backup systems

Advanced LiFePO4 Technology

  • High thermal stability and safety
  • Longer lifespan compared to traditional batteries

Long Cycle Life

  • ≥6000 cycles @ 80% DOD
  • Designed for long-term use

High Performance Charging

  • Supports 1C continuous charge/discharge
  • Max current: 100A

Smart Monitoring

  • Optional WiFi & Bluetooth connectivity
  • Real-time monitoring via mobile app

Compact Wall-Mounted Design

  • Space-saving installation
  • Clean and modern look for homes

Expandable System

  • Supports up to 16 units in parallel
  • Scalable energy storage solution

Built-in Display

  • 3.2-inch touch screen
  • Easy system monitoring and control

Wide Compatibility

  • Works with major inverter brands
  • Supports hybrid and off-grid systems

Enhanced Safety

  • IP20 protection
  • Certified with UN38.3, ROHS, MSDS
Technical Specifications
  • Model: ES-BOX42
  • Battery Type: LiFePO4 (Lithium Iron Phosphate)
  • Rated Energy: 5.12kWh
  • Rated Voltage: 51.2V
  • Capacity: 100Ah
  • Voltage Range: 44.8V – 56.8V
  • Max Charge/Discharge Current: 100A
  • Charge/Discharge Rate: 1C
  • Cycle Life: ≥6000 cycles (80% DOD)
  • Depth of Discharge: 80–90%
  • Communication: USB / RS485 / CAN
  • Display: 3.2” Touch Screen
  • Operating Temperature:
    Charging: 0°C to 55°C
    Discharging: -20°C to 55°C
  • Protection Level: IP20
  • Weight: ≤45kg
  • Dimensions: 485 × 480 × 155 mm
  • Parallel Support: Up to 16 units
  • Certifications: ROHS / UN38.3 / MSDS
  • Optional Features: WiFi / Bluetooth Monitoring

Applications

  • Home solar energy storage systems
  • Backup power for residential use
  • Hybrid inverter systems
  • Off-grid solar installations
  • Smart energy management setups

Solar Generators

Shop now

Solar Panels

Shop now

Frequently asked questions
What is the capacity of this battery?

The ES-BOX42 offers 5.12kWh capacity, suitable for home energy storage and backup.
Can I expand the system later?

Yes, it supports up to 16 batteries in parallel for increased capacity.
Is this battery compatible with my inverter?

It is compatible with most hybrid and off-grid inverters using RS485/CAN communication.
Does it support remote monitoring?

Yes, WiFi and Bluetooth monitoring (optional) allow real-time tracking via mobile apps.
How long does the battery last?

It provides 6000+ cycles, which typically translates to 8–12 years of usage depending on conditions.
