GoodWe ES G2 Series 3–6kW Single Phase Hybrid Inverter (LV)

GoodWe ES G2 Series 3–6kW Single Phase Hybrid Inverter (LV)

ES G2 – 3 kW
Rs.175,000.00
Skip to product information
GoodWe ES G2 Series 3–6kW Single Phase Hybrid Inverter (LV)
  • GoodWe ES G2 Series 3–6kW Single Phase Hybrid Inverter (LV)
  • GoodWe ES G2 Series 3–6kW Single Phase Hybrid Inverter (LV)
  • GoodWe ES G2 Series 3–6kW Single Phase Hybrid Inverter (LV)
GoodWe ES G2 Series 3–6kW Single Phase Hybrid Inverter (LV)

GoodWe ES G2 Series 3–6kW Single Phase Hybrid Inverter (LV)

Rs.175,000.00
Model
Description

Smart Hybrid Solar Inverter for Residential Energy Independence

The GoodWe ES G2 Series Hybrid Inverter is a next-generation single-phase solar inverter designed for residential energy storage systems. Available in capacities ranging from 3kW to 6kW, this advanced hybrid inverter enables homeowners to maximize solar self-consumption while maintaining reliable backup power during grid outages.

With its compact design, intelligent monitoring, and reliable backup functionality, the GoodWe ES G2 Series inverter is an ideal solution for homeowners seeking energy independence and efficient solar power management.

Available through US Solar Enterprises, the ES G2 Series delivers dependable performance for modern residential solar installations.
Key Features

Hybrid Solar Energy Management

Combines solar generation, battery storage, and grid power for optimized energy usage.

UPS-Level Backup Switching

Provides fast switching in less than 10ms, ensuring uninterrupted power supply to essential loads.

Dual MPPT Solar Optimization

Equipped with two MPPT trackers to maximize solar energy production across multiple panel strings.

Smart Monitoring & Control

Supports WiFi, LAN, and mobile app monitoring for real-time system performance tracking.

Compact & Lightweight Design

Plug-and-play design ensures quick installation and minimal maintenance.

Battery Compatibility

Compatible with GoodWe Lynx Home U low-voltage battery systems for efficient energy storage.

Flexible Power Range

Available models include 3kW, 3.6kW, 5kW, and 6kW output capacities to meet various residential energy needs.
Technical Specifications
  • Series: ES G2
  • Inverter Type: Single Phase Hybrid Inverter (LV)

Power Range

  • 3kW / 3.6kW / 5kW / 6kW models available

Battery

  • Battery Type: Lithium-ion
  • Nominal Battery Voltage: 48V
  • Battery Voltage Range: 40 – 60V

Solar Input

  • Max PV Input Power: up to 9000W
  • MPPT Voltage Range: 60 – 550V
  • Max PV Input Voltage: 600V
  • MPPT Trackers: 2

AC Output

  • Nominal Output Voltage: 220 / 230 / 240V
  • Frequency: 50 / 60Hz
  • Power Factor: Adjustable

Efficiency

  • Max Efficiency: 97.6%
  • European Efficiency: 96.7%
  • MPPT Efficiency: 99.9%

Environmental

  • Operating Temperature: −25°C to +60°C
  • Protection Rating: IP65

Installation

  • Mounting Type: Wall Mounted
  • Cooling Method: Natural Convection

Solar Generators

Shop now

Solar Panels

Shop now

Frequently asked questions
What battery works with the GoodWe ES G2 inverter?

The ES G2 Series is compatible with GoodWe Lynx Home U low-voltage lithium battery systems and other supported 48V battery solutions.
Can the ES G2 inverter provide backup power during outages?

Yes. The inverter offers UPS-level switching under 10ms, allowing critical household loads to continue running during grid failures.
What solar panel capacity can the ES G2 support?

Depending on the model, the inverter supports up to 9kW of PV input, allowing efficient solar power generation.
Does the inverter support smart monitoring?

Yes. The system includes WiFi, LAN, and mobile app monitoring, allowing users to track energy production and system performance in real time.
Is the ES G2 inverter suitable for residential installations?

Yes. The inverter is specifically designed for residential solar systems, providing reliable power, smart energy control, and backup capability.
